Hydraulic Butt Welder

SUD1000-1400 Butt Fusion Machine







BRIEF:

1. Consist of Basic frame, Hydraulic unit, Planning Tool, Heating Plate, Electric Control Unit and Support.

2.Removable PTFE coated heating plate with separate temperature control system.

3.  Electric Planning Tool with reversible double cutting edge blades.

4.  Hydraulic Unit provides welding machine with compressing power.

5. Be made of Aluminum  material, easy to carry and transport.

6. Low starting pressure ensures reliable welding quality of small pipes.

7. Temperature Controller and Timer,  "Sole" brand, high quality and best aftersales service.



MACHINE SPECIFICATIONS:

ModelSUD1000-1400
Welding Range (mm)1000, 1100, 1200, 1400
Heating Plate Max. Temperature270°C
Temperature Deviation in Surface≤10°C
Working Voltage380+10%, 50/60Hz
Heating Plate Power45KW
Planning Tool Power5.5KW (IP54)
Hydraulic Unit Power4KW (IP54)
Total Power54.5KW
Total Current65.25A
Pressure Adjustable Ranges0-20Mpa
Total Section of Cylinder32.97cm²
Oil Tank Volume60L
Weight5500KG
Optional Parts:

1. Hoist/Crane
2Trolley

3.
Stub End Holder
